Product Description
Dell Networking S5248-ON The PowerSwitch S5200-ON 25/100GbE fixed switches comprise Dell Technologies’ latest disaggregated hardware and software data center networking solutions, providing state-of-the-art, high-density 25/100GbE ports and a broad range of functionality to meet the growing demands of today’s data center environment. These innovative, next-generation open networking switches offer optimum flexibility and cost-effectiveness for web 2.0, enterprise and cloud service providers with demanding compute and storage traffic environments.
Features
1RU high-density ToR switches with up to 48 ports of 25GbE
Multi-rate 100GbE ports support 10/25/40/50/100GbE
Scalable L2 and L3 Ethernet switching with QoS and a full complement of standards-based IPv4 and IPv6 features, including OSPF and BGP routing support
Line-rate performance via non-blocking switch fabrics: 2.0Tbps (4.0Tbps full-duplex) on S5248FON
L2 multipath support via Virtual Link Trunking (VLT) and Routed VLT support
VXLAN gateway functionality support for bridging and routing the non-virtualized and the virtualized overlay networks with line rate performance
Support for Dell SmartFabric OS10
Added on:
06 November 2024
Specification
- Brand : Dell
- Ports : 48xSFP28 2xQSFP28-DD 4xQSFP28
- Max 10GbE density : 48 (SFP28) 16 (QSFP28-DD breakout) 16 (QSFP28 breakout)
- Max 25GbE density : 48 (SFP28) 16 (QSFP28-DD breakout) 16 (QSFP28 breakout)
- Switching capacity : 2.0 Tbps (4.0 Tbps full duplex)
- Latency (nano sec) : 847
- CPU Memory : 16GB
- SSD : 64GB
- Maximum power : 647W
- Typical power : 310W
- Form Factor : 17.1”Wx18.1”D x1.7”H
- Weight : 9.7kg (21.4lbs)
